| Basic |
| Power Supply | 400 VAC, 50/60 Hz, 3-Phase |
| Rated Power | 22 kW |
| Operating Current | 3 × 32 A max |
| Input Cable Wiring Method | N/R/S/T/PE |
| Socket Outlet or Connector Type | Socket, type 2 |
| Charging Protocol | Mode 3 (IEC 61851-1 compliant communication protocol) |
| Port |
| Charging Port | Type 2 (Socket, IEC 62196 Type2 EU) |
| Ethernet Port | 1 × RJ-45 (100 Mbps Ethernet network port -IEEE1588) |
| Function |
| Display Screen | 7 inch LCD (Wide Video Graphics Array), it displays the charging current, charging voltage, charging power, charging time, status, failure information and more. |
| Front LED Indicator | Indicates the status of the charge using different colors
Blue: Stand-by mode;
Yellow: Ready to be used;
Green: Charging;
Red: An issue with the charge |
| Communication Protocol | OCPP 1.6J, ModBus TCP |
| Charging Mode | Free vending mode (plug&play), RFID control mode (built-in RFID reader, ISO 14443- A, 13.553 MHz–13.567 MHz), and App control by Wi-Fi (2412 MHz–2484 MHz) |
| Upgrade Method | USB upgrade and remote upgrade (OCPP 1.6J) |
| Safety Protection | Surge protection, over temperature protection, over voltage protection, under voltage protection, over current protection, grounding protection, electrical leakage protection |
| Earth Leakage Protection | Integral 30 mA Type A and DC 6mA RCD function protection |
| PEN Protection | Integrated broken PEN lead protection according to BS 7671:2018/A1:2020 |
| Remote Diagnostics | Remote diagnostics over OCPP 1.6J |
| Energy Monitoring | Internal MID meter monitors power and energy |
| Dynamic Load Management | Dynamic load management via Ethernet, Wi-Fi and OCPP 1.6J |
| Charging Current Value | 10 A–32 A (Adjustable) |
| General |
| Operating Temperature | –30 °C to +65 °C (–22 °F to +149 °F) |
| Storage Temperature | –40 °C to +75 °C (–40 °F to +167 °F) |
| Operating Humidity | ≤95% (RH), non-condensing |
| Product Dimensions | 410 mm × 295 mm × 137 mm (16.14" × 11.61" × 5.39") (L × W × H) |
| Packaging Dimensions | 550 mm × 430 mm × 320 mm (21.65" × 16.93" × 12.60") (L × W × H) |
| Net Weight | 9.65 kg (21.27 lb) |
| Package Weight | 12.2 kg (26.90 lb) |
| Installation Environment | Indoor and outdoor |
| Installation | Wall mount and floor standing |
| Wire | Wire cross-section: 5 × 6 mm2 (9 AWG) |
| Certifications | CE
EN IEC61851-1, EN IEC61851-21-2, EN300328, EISI EN300330,
EN301489-1/-17/-3/-52, EN62311, EN50364, ETSI EN 301511,
ETSI EN301908-1/-2/-13, IEC62955, 2011/65/EU, 2015/863/EU |
| Protection | IP65 |
| Anti-collision Grade | IK10 without LCD display, IK08 for all |
| Material | Aluminum alloy and steel |
